5.56 vs .223 | Whats The Difference | Ballistics

What is the key difference between 223 and 556?

• The main difference between these two cartridges is the pressure they are loaded to.
• The 5.56 NATO cartridge is loaded to a higher pressure of 58,000 psi whereas a .223 round is loaded to 55,000 psi.
• Likewise, the heavier 62-grain M855 NATO round is roughly 13% more powerful than the 223 Remington round resulting in a pressure of roughly 62,366 psi.

You can imagine what would happen if you chose to fire that out of a 223 Remington.

Cartridge Differences

Aside from the pressure differences, the throat (sometimes referred to as the leade) of 5.56 rifles is slightly longer to accommodate the higher pressure and sometimes heavier bullet weights.

What is leade? It’s the distance between the case mouth and barrel rifling. .223 commonly has a shorter leade than 5.56; roughly a difference of .125”. The small amount is enough to cause deadly issues when attempting to shoot 5.56 out of a .223,

Why the difference in the leade? 5.56 was originally designed for the military to be reliable and function under harsh field conditions. These harsh conditions could lead to dirt and debris getting into the chamber as well as carbon buildup. Our warfighters need a round that will function in all conditions without the need to stop and clean their firearm.

To meet those requirements, the chamber of a 5.56 NATO rifle is designed slightly larger for increased reliability. The slightly longer leade and shallow feed ramp angle enhance feeding and reliability by reducing the amount of carbon buildup and debris hanging out in the chamber.

The design concept is similar to that of the AK-47. Keep the tolerances a bit looser to get better reliability.

All that said, a common question arises regularly; Can you shoot 5.56 ammo out of a .223 rifle and vice versa?

Due to the increased pressure of a 5.56 cartridge and the slight difference in the chamber size, you should NEVER fire a 5.56 out of a .223. Doing so risks catastrophic damage to the shooter and rifle. You’d be shooting a higher-pressure round out of a smaller chamber.

However, you can safely shoot .223 ammunition out of a 5.56 rifle. The only issue you may experience is decreased accuracy due to the leade difference.

What’s the Difference in ballistics between .223 and 5.56

The three categories we’re going to look at are velocity, energy, and trajectory (drop) out to 500 yards.

In the Marine Corps, we were taught that the max effective range of our M16/M4 was 500 yards, so that’s why we’re using that as a reference.

The load we’re using in this example is the standard 55-grain FMJ.

Velocity

Velocity is the most important of the three, as it has an impact on the energy delivered to the target as well as the rise and fall of the flight path.

As you can see the 223 has a slightly higher velocity than the 5.56. This is mainly due to the chamber design and twist rate. The 223 Remington has a tighter chamber which results in increased accuracy over the 5.56 NATO.

Energy

Energy becomes important when discussing “hunting” and home defense. Energy can be translated to stopping power or energy on target. When the bullet impacts the target, it dumps all it’s energy into said target. The more foot pounds of energy you can dump into the target, the better terminal results you’ll have.

As you see in the chart above, the 5.56 outpaces the 223 Remington when it comes to energy on target. This can be due to the higher pressure it’s loaded to as well as the weight of the projectile.

Becuase the energy has such a significant drop past 300 yards, we always used the M16/M4 for engagements from CQB distances out to 300 yards.

Speaking of energy on target and 223 Remington, another great option here is frangible ammo. Check out this article over on RE Factor Tactical where they discuss using 223 Frangible ammo for home defense.

Trajectory

The trajectory or flight path of a bullet impacts the shooter’s ability to accurately hit the target. Knowing the trajectory of your ammo will allow you to make the necessary adjustments to be accurate. These adjustments will be different between the two cartridges.

The 5.56 NATO round has a roughly 3-inch drop at 200 yards and increases to an 11.25-inch drop at 300 yards.

The 223 Remington will drop roughly 4.2 inches at 200 yards. Although the 223 has a higher velocity, the 5.56 has less drop at distance, resulting in more consistent combat-effective hits at distance.

What is 223 Wylde?

When discussing .223 and 5.56, 223 Wylde commonly gets thrown into the mix. Why?

Well as we’ve discussed the difference between 223 and 556 and the consequences of firing a 5.56 out of a 223, what if we had a hybrid rifle or barrel that you could safely shoot both calibers from? Enter the 223 Wylde.

A rifle chambered in 223 Wylde gives you the ability to shoot both 223 Remington and 5.56 NATO ammunition out of the same rifle.

The design of the 223 Wylde barrel incorporates the 5.56 leade angle and chamber size and the freebore concentricity of the 223 Remington.

By doing so, the 223 Wyle maintains the reliability of the 5.56 while giving you the accuracy of the .223 Remington.

What is the NATO designation of 5.56?

The NATO designation refers to ammunition designed with certain specifications to be used by NATO forces.

If you placed a 223 Remington and 5.56 NATO side by side, the only way you would be able to tell the difference is to look at the headstamp for the NATO designation.

Once you’ve identified it’s a NATO round, you know that it’s loaded to a higher pressure and cannot be fired out of a rifle chambered in 223 Remington.

Should I buy .223 or 5.56?

The short answer is to know what your rifle is chambered in and ensure you’re buying the correct ammunition.

If your rifle is chambered in .223 Remington, then that’s the ammo you need to buy. Likewise, if you’re rifle is chambered in 5.56 NATO, which most are, then ensure you’re buying 5.56 ammo.

If and when you shoot your barrel out and need to replace your barrel, that’s a great time to evaluate getting a 223 Wylde barrel so that you have the capability of shooting both rounds out of your rifle.

Conclusion

The 223 Remington and 5.56 NATO are two of the most popular rounds for the modern AR-15 era.

Although they have identical external dimensions and case capacity, the 5.56 is loaded to a higher pressure.

Due to the higher pressure, it is highly discouraged to fire 5.56 out of a rifle chambered for 223 Remington.

You can, however, safely fire a 223 round out of a rifle chambered for 5.56. The only negative impact you may see is accuracy.

If you don’t want to worry about which ammo to use in your AR-15, then you can either buy a rifle chambered in 223 Wylde or swap your existing barrel for a .223 Wylde barrel.

Once you’ve settled on what ammunition to use out of your rifle, buying that ammo in bulk is going to save you money in the long run. Be sure to check out our stock of 223 ammo and 5.56 ammo!



**Originally published on HOP Munitions
